Scientific Article
Auralization based on multiperspective ambisonic room impulse responses
Institute of Electronic Music and Acoustics, University of Music and Performing Arts Graz, 8010 Graz, Austria
^{*} Corresponding author: zotter@iem.at
Received:
28
May
2020
Accepted:
10
October
2020
Most often, virtual acoustic rendering employs realtime updated room acoustic simulations to accomplish auralization for a variable listener perspective. As an alternative, we propose and test a technique to interpolate room impulse responses, specifically Ambisonic room impulse responses (ARIRs) available at a grid of spatially distributed receiver perspectives, measured or simulated in a desired acoustic environment. In particular, we extrapolate a triplet of neighboring ARIRs to the variable listener perspective, preceding their linear interpolation. The extrapolation is achieved by decomposing each ARIR into localized sound events and reassigning their direction, time, and level to what could be observed at the listener perspective, with as much temporal, directional, and perspective context as possible. We propose to undertake this decomposition in two levels: Peaks in the early ARIRs are decomposed into jointly localized sound events, based on time differences of arrival observed in either an ARIR triplet, or all ARIRs observing the direct sound. Sound events that could not be jointly localized are treated as residuals whose less precise localization utilizes directionofarrival detection and the estimated time of arrival. For the interpolated rendering, suitable parameter settings are found by evaluating the proposed method in a listening experiment, using both measured and simulated ARIR data sets, under static and timevarying conditions.
Key words: 6dof rendering / Room impulse responses / Variableperspective rendering / Virtual acoustics
© K. Müller & F. Zotter, Published by EDP Sciences, 2020
This is an Open Access article distributed under the terms of the Creative Commons Attribution License (https://creativecommons.org/licenses/by/4.0), which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited.
1 Introduction
An interactive, variable listener perspective in virtual acoustic environments necessitates rendering of movements in six degrees of freedom (6DoF), i.e. auralization for arbitrary translation and orientation of a listener. Utilizing room simulations is a common means to achieve variableperspective audio rendering [1–3]. Naturally, such auralizations require a certain level of sophistication to reach authenticity even in static scenarios, and they should moreover ensure smooth transitions when the listener position is timevariant. A comparison of recent room simulation algorithms revealed that auralizations are perceived to be mostly plausible, although not authentic [3]. This motivates the development of approaches based on multiperspective recordings or measured natural acoustic environments as alternatives, and the development of perspective interpolation approaches as helpful simplifications.
There are recent works that extrapolate singleperspective, first or higherorder Ambisonic recordings by projecting directionally localized sound objects onto a outer convex hull or onto predefined virtual room walls to achieve auralization in 6DoF [4–8]. Other approaches use planewave translations for variableperspective auralization of single Ambisonic recordings [9, 10]. However, these methods mostly become inaccurate for great extrapolation distances.
To enable position shifts in a wider area, one can consider interpolating between Ambisonic recordings captured at multiple perspectives in the room simultaneously. While basic approaches apply a distanceweighted linear interpolation of the recorded perspectives near the listener [11, 12], parametric methods mostly use spatial timefrequency processing to extract and localize sound sources in order to synthesize them at a desired listener perspective [13–16], mixed with diffuse or unlocalized sound field residuals. A detailed overview of existing methods is provided in [17]. To avoid typical artifacts of signaldependent timefrequency filtering, some other works render audio in 6DoF using broadband processing [18–21], which, however, would stay limited in spatial precision.
Auralization by convolution with measured multiperspective directional room impulse responses (DRIRs) is an alternative to the rendering of multiperspective surround recordings. Such a convolution approach complies with typical auralization, in which the directional impulse response is obtained from roomacoustics simulation. Despite a measured multiperspective DRIR grid is expected to be much coarser, it is interchangeable with simulation to some degree. In contrast to Ambisonic or surround recordings, a convolution approach allows to auralize any singlechannel signal in the desired spatial environment. And most importantly, measured DRIRs provide better accessibility to parametric decomposition of the captured acoustic environment, when compared to recorded signals. In particular, parametric decomposition is simplified by the temporal and directional sparsity of the sound events arriving in the early DRIR. Consequently, multiperspective DRIRs enable a more detailed morphing of sound events observed at the recording perspective towards such observed at another, extrapolated perspective. The availability of multiple perspectives allows to superimpose their perspective extrapolation for interpolation.
As an example, binaural room impulse responses (BRIRs) are commonly used as DRIRs to interface with headphone playback. Some variableperspective rendering methods work with crossfading between spatially distributed BRIRs [22, 23]. More sophisticated decomposition algorithms employ dynamic time warping [24–26]. However, fixedorientation BRIRs do not provide an easy implementation of dynamic head rotation, and thus 6DoF approaches usually require to be fed with dummy head measurements done in multiple head orientations for every perspective [27, 28], which is exhaustive in terms of data and measurement effort. An approach described in [29] reduces the effort to a singleperspective BRIR measurement, however with multiple source directions and distances.
Alternatively to auralization from interpolated BRIRs, auralization can also be based on convolution with Ambisonic room impulse responses (ARIRs) as DRIRs. Other than with BRIRs, the convolution with ARIRs generates Ambisonic signals that are freely rotatable and can be decoded to both loudspeaker arrays and headphones. For single perspectives, there are multiple works presenting an efficient parameterization and directional enhancement of firstorder Ambisonic room impulse responses using SIRR, SDM, ASDM [30–33]. Hence, auralization of translatory movements based on spatially distributed ARIRs is a promising approach for variableperspective audio rendering. A suitable set of multiperspective DRIRs could consist of Bformat RIRs [34], i.e. firstorder ARIRs.
Clearly, the known variableperspective rendering methods [11–16, 18] could be applied to multiperspective ARIRs. For instance, a distanceweighted, linear interpolation of the ARIRs closest to the desired listener perspective [35] is probably the most basic approach for variableperspective rendering. However, as this and most of the known more sophisticated methods are designed to interpolate recorded Ambisonic signals rather than ARIRs, we expect an unused potential for a strong increase in spatial definition. This is because ARIR interpolation permits to employ methods that take advantage of the temporal sparsity and spatial localizability in the early ARIR parts. In particular, spatial resolution could be vastly improved when extracting and localizing highenergy sound events by incorporating temporal and directional information that is contained in multiperspective ARIRs. The works [24, 25] describe an interpolation approach for firstorder ARIRs based on dynamic time warping (DTW) that ensures temporal matching of the interpolated ARIRs. However, DTW does not enforce a geometrically consistent mapping of times, levels, and directions yet. A more elaborated method derived from DTW employs firstorder ARIR interpolation including peak detection and matching, and a separate interpolation of directions of arrival [36].
To moreover ensure geometrical consistency exploiting the information available, our contribution introduces perspective interpolation from a spatially distributed ARIR triplet in Section 2. It employs extrapolation of the three ARIR perspectives based on localized instantaneous sound events, and it linearly interpolates the three ARIRs subsequently (cf. Fig. 1). Furthermore, we review the ASDM technique for directional resolution enhancement of firstorder ARIRs by upmixing to higher Ambisonic orders, as reasonable extension of the ARIR interpolation. In Section 3, we propose an approach to extrapolate single ARIRs that restores temporal context within the ARIR using a simplistic soundevent localization and resampling technique. Section 4 introduces a more contextual, joint localization of sound events from time differences of arrival and directions of arrival observed in all ARIRs for the direct sound, and in a triplet of neighboring ARIRs for early reflections. For early sound events after the direct sound, the proposed approach detects and matches peaks in the ARIR triplet that are assumed to belong to the same sound event. The resulting extrapolation is described and how interpolation artifacts are avoided by timealigning the ARIR segments of matched sound events. In Section 5 we combine both extrapolation techniques to propose a variableperspective ARIR rendering that is based on (i) positiondependent interpolation of jointly localized, matched ARIR peaks, and (ii) separately extrapolated, residual ARIRs; for both, rendering recombines measured ARIR segments of a triplet of perspectives (cf. Fig. 1). To support realtime operation, an offlineinterpolated, finemeshed ARIR grid is proposed to simplify the interpolation. Finally, different configurations of the proposed interpolation are evaluated in a listening experiment using both measured and simulated firstorder ARIR data sets, in Section 6.
Figure 1 Rendering of a variable listener perspective by interpolation of the three closest ARIR perspectives of a spatially distributed ARIR grid. Before interpolation, the three ARIRs are extrapolated to the desired listener perspective x_{d} by decomposition into localized sound events, which are reproduced at the listener perspective with reassigned direction, time, and level.
2 Proposed perspective interpolation
The proposed interpolation consists of the perspective extrapolation of measured or simulated Ambisonic room impulse responses (ARIRs) to the desired listener perspective and their linear interpolation within a constellation of a triplet around the listener, as shown in Figure 1.
2.1 ARIRtriplet interpolation
For interpolation, we propose to linearly superimpose the ARIR triplet around the listening position with weights depending on the variable position. As shown in [11, 35], a purely distanceweighted linear interpolation yields a fair directional reproduction of a recorded sound field. Therefore, we initially introduce distance weights g_{i}(x_{d}) that specify the contribution of each ARIR of the triplet h_{i}(t), i ∈ {1, 2, 3} to the interpolated result by emphasizing close ARIRs and attenuating distant ones. For a horizontal, equidistant square ARIR grid with z_{i} = 0, it can be defined by,(1)with the grid positions x_{i} = [x_{i}, y_{i}, z_{i}]^{T} and listener perspective x_{d} = [x_{d}, y_{d}, z_{d}]^{T}. r is the grid spacing of neighboring ARIRs and G is chosen so that g_{i}(x_{d}) = 1. The according interpolation of ARIR triplets would yield,(2)where d(t) denotes the interpolated ARIR at the desired listener perspective x_{d}.
However, the purely distanceweighted, linear interpolation alone can cause problems such as strong comb filtering artifacts due to the temporally and directionally misaligned superposition of the direct sound peaks or prominent early reflection peaks. Hereby, linear interpolation can smear such peaks either temporally or directionally, causing either an increased number of apparent peaks that are too low in amplitude or which may lack energy in the higherorder channels. Most often, this causes perceivable fluctuations of sound coloration or room impressions (distance, width) when moving through the virtual room, which is also reflected in the evaluation (cf. Sect. 6). Superior performance is expected when interpolation is preceded with perspective extrapolation, i.e. a prior parametric translation of the measured ARIR perspectives to the desired listener perspective.
2.2 ARIR extrapolation
The proposed perspective extrapolation decomposes an ARIR into short time segments, of which each one is interpreted as an instantaneous sound event, corresponding to an acoustic propagation path, e.g. a discrete reflection, in the room. Extrapolation ensures that sound events, such as peaks in the ARIRs, get timealigned, levelaligned, and directionaligned consistent with what should be received at the variable listening perspective. And yet, extrapolation should be as contentpreserving as possible, and therefore its alignments in time, level, and direction within the ARIRs need to be done carefully. For instance, alignment needs not be processed individually for every sample of the ARIR if the temporal context can be preserved with a constant time shift of finite time segments. Directional alignment needs not destroy directional context if it can be done by rotation.
The perspective extrapolation of a single ARIR time instant or segment h_{i}(t) from the ARIR perspective x_{i} to the desired listener perspective x_{d} is done assuming a known instantaneous soundevent position locating the ARIR time instant or segment in space (cf. Fig. 2).
Figure 2 Extrapolation of an ARIR segment from its recording perspective x_{i} to a desired listener perspective x_{d}, given its instantaneous soundevent position .
2.2.1 Rotation
As a first step, extrapolation applies a rotation to the soundevent direction of arrival (DOA) θ_{d}() that is consistent with what a listener should receive at the translated position. The rotation is accomplished by multiplying the ARIR time instant or segment with an Nthorder spherical harmonics rotation matrix (6) that is determined by a Cartesian 3 × 3 rotation matrix R_{xyz}(). The rotation aligns the observed DOA in form of the Cartesian unit vector θ_{i}() with the DOA θ_{d}() at the target perspective, i.e. θ_{d}() = R_{xyz}()θ_{i}(), in azimuth and zenith,(3)where φ_{i,d} is the azimuth and ϑ_{i,d} is the zenith of the corresponding DOA,(4)
The azimuth φ and zenith ϑ of a Cartesian unitlength DOA vector θ = [x, y, z]^{T} can be determined by,(5)
The Nthorder spherical harmonics rotation matrix,(6)is determined from (3) by recurrence relations according to [37]. We used the implementation contained in the Spherical Harmonic Transform^{1} Matlab Toolbox.
2.2.2 Time and level adjustment
Moreover, extrapolation of an ARIR time instant or segment implies a distance shift ΔD_{i}() that physically corresponds with a shift in level (8), according to the distance law, and in time (9), according to the acoustic flight time. Altogether, the corresponding ARIR segment extrapolation becomes,(7)(8)(9)with the distances and . The result denotes the extrapolated ARIR time instant or segment that is consistently displaying the instantaneous soundevent position observed at the new perspective x_{d}.
As firstorder multiperspective ARIR measurements are still easier to take, more easily available, or less costly because they can be taken with firstorder tetrahedral microphone arrays, we propose their directional enhancement in the upcoming section, as modular tool to improve the directional resolution of firstorder ARIRs to higher order. Higherorder ARIRs are not only superior in terms of their directional definition [38], we also assume their interpolation to be safer in avoiding audible interference artifacts.
2.3 Directional enhancement of firstorder ARIRs
Directional enhancement is a means to improve the perceived spaciousness of firstorder ARIRs, i.e. Bformat RIRs. Merimaa and Pulkki introduced the spatial impulse response rendering (SIRR) [30], which assumes the existence of numerous timevarying narrowband sources within an otherwise isotropic, diffuse sound field. They first estimate the diffuseness and DOA of each timefrequency bin to map nondiffuse RIR content to a loudspeaker array according to the estimated DOAs using vector based amplitude panning (VBAP). The diffuse RIR part is decorrelated and mixed to all loudspeakers. A recent work [39] introduced a SIRR approach for higherorder input and moreover investigated the perceived effect of different SIRR configurations in comparison to the firstorder spatial decomposition method (SDM).
The SDM proposed by Tervo et al. [31] is more simplistic and does not differentiate between diffuse and nondiffuse RIR content and is designed in time domain only. It assumes that a single timevarying direction as carrier of the sequence of broadband sound events in the RIR is sufficient to model the directionally incoming waves. While this assumption is mostly true for the early, sparse RIR part, it does not hold for the diffuse reverberation at later times, which is characterized by multiple coincident reflections from several directions. The authors of SDM suggested to map SDMencoded RIRs to a loudspeaker array via VBAP or to the nearest loudspeaker.
Instead of mapping firstorder ARIRs to a specific loudspeaker array, recent publications propose to directively reencode RIR sound events in higherorder Ambisonics. The SDMbased approach by Zaunschirm et al. [32] is called Ambisonic spatial decomposition method (ASDM). Similar as the earlier works, it uses a Cartesian directionofarrival (DOA) vector θ(t) estimated from the smoothed pseudo intensity vector (t) of a bandlimited, firstorder ARIR,(10)where W(t) is the zerothorder omnidirectional ARIR channel of the firstorder ARIR h(t) and {X, Y, Z}(t) are the firstorder directional ARIR channels pointing to x, y, and z. The subscript {∙}_{BP} denotes zerophase bandpass filtering between 200 Hz and 3 kHz and F_{av}{∙} is a zerophase averaging filter over 10 samples at sampling rate f_{s} = 44.1 kHz, cf. [40]. This DOA estimation is also applicable to higherorder ARIRs by neglecting the channels of the order n ≥ 2.
Subsequently, ASDM encodes the omnidirectional RIR W(t) by N3Dnormalized, realvalued spherical harmonics of order n and degree m, evaluated at the directions θ(t),(11)where, e.g., N = 5 denotes the increased Ambisonic order. To revoke spectral whitening of the reverberation induced by fast DOA fluctuations whose higherorder encoding yields amplitude modulation, a spectral correction of the temporal envelope is introduced in [32], including a sourcecode example for MATLAB.
As stated above, the fundamental SDM assumption of only one single broadband sound event per time instant is usually violated when reverberation gets diffuse. Therefore, we extend the ASDM directional enhancement by a decorrelation of the late ARIR part for t > 100 ms as described in ([38], Ch. 5) with the modulation parameters τ = 5 ms and = 50°,(12)where J_{q}(·) is the orderq Bessel function of the first kind and are the Ambisonic channels of the spectrally corrected ARIR.
We propose the singleperspective resolution enhancement as initial step of the variableperspective ARIR interpolation when using firstorder ARIR grids. Hereafter, h_{i}(t) thus denotes higherorder ARIRs whose directional resolution was either enhanced from first order, which were directly captured with higherorder microphone arrays, or simulated.
3 Singleperspective ARIR extrapolation
As a first approach, one can think of an independent extrapolation of every ARIR, disregarding the context of neighboring ARIRs. As proposed in Section 2.2, such an independent extrapolation could be based on the estimation of an instantaneous soundevent position.
3.1 Instantaneous sound events in single ARIR
We propose to estimate the instantaneous soundevent position for each sample of the ith ARIR h_{i}(t) using its DOA θ_{i}(t) (10) and estimated time of arrival (TOA) t (note that the ARIR set should be compensated for a possible measurement delay or predelay truncation, which is estimated in Section 4.3),(13)
Each ARIR sample can be interpreted as singlesample sound event that is emitted from the according instantaneous soundevent position at time t = 0. Observing these spatial ARIR samples from an extrapolated listener perspective x_{d} would yield a samplewise parallactic time shift, distance shift and rotation as described in Section 2.2 (7).
Figure 3a shows an exemplary trajectory of instantaneous sound event positions (gray) containing three ARIR segments of equal duration t_{1} ≤ t ≤ t_{2} (blue), t_{3} ≤ t ≤ t_{4} (red) and t_{5} ≤ t ≤ t_{6} (green) on straightline trajectories. With regard to the recording perspective, the corresponding TOAs are proportional to the radial coordinate (top axis) in Figure 3a. Whereas the direction and level of each spatial ARIR sample can be directly adapted to the extrapolated listener perspective x_{d} according to (8) and (6), a parallactic temporal resampling per sample (9) would destroy the temporal ARIR context and yield coloration by timescale distortion of ARIR segments, such as timereversal (blue), temporal expansion (red) or compression (green), as displayed by the radial coordinate with regard to the listener (bottom axis) in Figure 3a. This temporal and spectral distortion may cause a distinct loss of sound quality.
Figure 3 Schematic illustration of singleperspective extrapolation by instantaneous soundevent trajectory (gray) according to (19) with three straightline segments , , of equal duration in the recorded ARIR (top time line). While level and direction remapping according to (a) are acceptable, temporal remapping (bottom time line) improves by resampling at original sampling speed, with segment time shifts quantized as their median time shift (b) (bottom time line).
3.2 Extrapolation restoring the temporal context
To prevent the timescale warping, we introduce a quantized timeshift map constraining temporal resampling to the original sampling rate within variablelength ARIR segments. To this end, the captured ARIR is split into shorttime segments, whose time shifts Δt_{i}() (9) are quantized within each segment by its median value. The accordingly durationpreserving TOAs are displayed with regard to the listener perspective in Figure 3b along the radial coordinate (bottom axis). For most accurate results in the early ARIR, segmentation should consider detecting ARIR peaks and defining preferably long nonoverlapping segments containing single distinct sound events. As we propose a more elaborate, separate extrapolation of prominent ARIR peaks that can be localized in an ARIR triplet in Section 4, the variablelength segmentation employed here is more simplistic and divides the ARIR into segments between jumps in the parallactic time shift Δt_{i}(), with short cross fades in between. Segment boundaries are accordingly defined at the extrema of . We implemented the extrema detection by a window of length L around t running over Δt_{i}() starting from t = 0. For each time instant t, the global maximum within the sliding window is defined as preliminary segment boundary, whereas remaining local maxima within the window are rejected. If the preliminary segment boundary is globally maximal in all the sliding windows it is contained in, it becomes a segment boundary. For implementation, we chose L = 16 samples at f_{s} = 44.1 kHz, which ensures variable segment lengths of L samples or more, and we employed –samples cos^{2} cross fades between the segments. An exemplary parallactic timeshift map Δt_{i}() (gray) and its quantized version (blue dotted) are shown in Figure 4 for a measured ARIR.
Figure 4 Time shifts due to parallactic resampling of the instantaneous soundevent position from an extrapolated listener perspective at a displacement of x_{d} − x_{i} = 1 m and segmentation with medianquantized time shifts.
Extrapolation thus initially applies the computation of a rotated (10) and leveladapted (12) ARIR,(14)and subsequently incorporates the medianquantized time shifts of the resulting ARIR. Finally, the windowed and timeshifted segments are superimposed to an extrapolated ARIR .
While the assumptions employed in the perspective extrapolation approach should hold for early ARIR sound events that are most often temporally and directionally distinct, they would likely be violated in later ARIR parts. Therefore, rather than reencoding at single directions, rotation is considered to more robustly preserve nonunique directional content. Moreover, studies on mixing time [41, 42] indicate that sufficiently late parts can be exchanged without audible effects, as their spectral properties are quite similar after a change in perspective. We restrict the perspective extrapolation to the first 100 ms as this adjustable limit worked well for both scenarios evaluated in Section 6.
4 Multiperspective ARIR extrapolation
The extrapolation in Section 3 can only deliver an adjustment of delay, gain, and direction of an individual ARIR perspective (P = 1) to the listening position, devoid of possible context that could be retrieved from multiple ARIR perspectives.
Whenever clear constellations of arrival times are observed in ARIRs captured at neighboring positions, a more systematic, joint soundevent localization becomes possible. We assume clear constellations to apply to highenergy sound events in the early, sparse ARIRs, such as the directsound peak or early reflections, which would provide an accurate estimation of arrival times. Consequently, a corresponding extrapolation from jointly localized temporal peaks as sound events could avoid the samplebased rotations and time shifts from Section 3.2, and it could hereby preserve longer temporal and directional contexts within time segments around highenergy ARIR peaks. Moreover, localization based on arrival times is assumed to offer a substantially higher localization accuracy compared to a singleDOAbased localization, because of the large spacing between neighboring perspectives.
This section first introduces the detection and fundamental parameter estimation of ARIR peaks. While the targeted variableperspective ARIR rendering is applicable to ARIRs of arbitrary order, the parameters are estimated from components of the zeroth and the first order. Secondly, the proposed approaches for joint soundevent localization are introduced, which in particular include a global localization of the directsound source and a tripletbased soundevent localization of early peaks, that could, e.g., relate to image source positions of early reflections, based on the observed TDOAs and DOAs. Finally, the extrapolation of ARIR segments around jointly localized sound events is described.
4.1 TOA, DOA and magnitude of ARIR peaks
To detect meaningful time instants of sound events, we propose an ARIR peak detection based on a shorttime magnitude of the directional content, represented by the envelope of both the omnidirectional and the firstorder directional ARIR channels. It can be computed from the averaged magnitude of the pseudo intensity vector I(t),(15)without band limitation, and here F_{H}{·} denotes a Hammingwindowed movingaverage filter over 0.5 ms. Each maximum of (t) that overshoots a predefined prominence threshold is defined as peak with time of arrival (TOA) T. The threshold is best chosen depending on the reverberation of the room, trading off the number of distinct peaks detected and their reliability by disposing lowenergy peaks. From the timevarying DOAs of (10), a static DOA θ(T) can be assigned to each time segment containing a detected peak.
In summary, we get a characteristic TOA T, minus a general offset that is yet unknown (cf. Sect. 4.3), a magnitude (T), and the DOA θ(T) of each prominent peak detected in the early ARIR h(t).
4.2 TDOAbased soundevent localization
DOAbased source localization is known from approaches using Ambisonic recordings from multiple perspectives [13, 14, 43]. However, a purely DOAbased localization of sound events from ARIR peaks can be inferior in precision. An arrivaltimebased source localization offers a reasonable alternative of potentially higher accuracy. Since measured RIRs can contain an unknown system delay, or more often than not a common predelay is removed, their time differences of arrival (TDOAs) are considered as information available from a grid of measured multiperspective RIRs or ARIRs. We propose a predominantly TDOAbased localization to achieve accuracy and robustness to measurement uncertainties.
4.2.1 Leastsquares localization
A detailed overview over existing passive source localization approaches is given in [44]. We suggest a localization based on the spherical leastsquare (LS) error (16) introduced by Schau et al. in [45]. For mathematical simplification, the coordinate system is initially shifted so that an arbitrary ARIR of the grid, defined as the first ARIR, is located in the origin, i.e. x_{1} = . The 3dimensional spherical LS error function is defined by,(16)where is the unknown distance of the unknown soundevent position x_{t} to the first ARIR perspective at x_{1} = . is the known setup distance between the ith and the first ARIR perspective for i ∈ {2, …, P}, where P denotes the total number of ARIR perspectives included in localization. Furthermore,(17)are the observed TDOAdependent range differences between the ith and the first ARIR according to the peak TOAs T_{i} and T_{1}, where c is the speed of sound.
Equation (16) is designed for 3dimensionally distributed receiver arrays. The 3D spherical LS error is equivalent to a 2D spherical LS error for a purely horizontal ARIR grid as the last column in S with z_{i} = 0, ∀i vanishes and suppresses z_{t}, leaving only a dependency of r_{t} on the height z_{t} of the sound event,(18)
Accordingly, the LS cost function yields(19)
It vanishes at its optimum for P = 3 and exhibits nonzero minima for P > 3, when assuming the presence of typical measurement uncertainties. In this case, soundevent localization is done by minimizing,(20)
4.2.2 Nonuniqueness in height z_{t}
As the 2D spherical LS cost function only contains a dependency of r_{t} on z_{t}, the sign of z_{t} is not determined and J_{sp,2D}([x_{t}, y_{t}, z_{t}]^{T}) = J_{sp,2D}([x_{t}, y_{t}, −z_{t}]^{T}). For P > 3, we get two minimumLS soundevent locations at ±z_{t,LS}, in general. For P = 3, the LS cost function vanishes for any preselected z_{t}, yielding infinitely many soundevent locations on a vertically symmetric hyperbola (cf. Fig. 5). In either case, P = 3 or P > 3, the 2D LS criterion alone is nonunique. To solve this ambiguity, we extend the LS cost function by an angular error function (21). Specifically, the DOAs of the resulting ambiguous soundevent candidates θ_{x,i}(x_{t}) are projected on the observed soundevent DOAs θ_{i}(T_{i}), ∀i,(21)
Figure 5 TDOA and DOAbased soundevent localization of the first early reflection (firstorder floor reflection) in an ARIR triplet. The cross marks the detected soundevent position, i.e. the point on the TDOAlocalized hyperbola with minimum angular deviation to the estimated DOAs. The directsound source is displayed as gray loudspeaker.
The unique soundevent location is found as minimum of,(22)
4.2.3 Ambiguity of peak combinations
While the first peak in every ARIR typically belongs to a single directsound event, assuming the absence of occlusion, the grouping of later arrival time constellations into distinct sound events is not as trivial. After the first peak, possible ARIR peak constellations can overlap in time, yielding a combinatorial ambiguity. The number of possible peak combinations rises drastically when many ARIRs are included. This is because the number of peak constellations to be matched grows exponentially with the flight time range within which physical peak combinations are searched. Therefore, a global matching of early ARIR peaks including a global localization of corresponding soundevent positions is impractical.
We propose global localization only for the first peak in every ARIR (P > 3) to get a stable directsound event. For the most prominent early ARIR peaks after the direct sound, we propose to use soundevent localization and matching within triplets of neighboring ARIR perspectives (P = 3) (cf. Sect. 4.5), taking into account salient peak features (cf. Sect. 4.1). Remaining, less distinct early ARIR peaks, especially the later peaks present in the early ARIR part, may be smeared making its correct detection and matching difficult. But by their low prominence, these peaks are also assumed to be less critical so that singleARIR soundevent localization (P = 1) should work accurately enough for them.
4.3 Global direct sound localization
As the directsound event is typically predominant and specifies the perceived direction due to the precedence effect, its extrapolation imposes the highest consistency and smoothness requirement when rendering for a listener that moves through different local ARIR triplets. To ensure a perfectly stable trajectory of the directsound event, we suggest a global directsound localization using all ARIR perspectives that receive the directsound event, if the directsound location is not known from the ARIR measurements. The TDOAs between directsound peaks in multiple perspectives can be estimated at high accuracy and enable robust localization. This can be accomplished, e.g., using the linear correction leastsquares (LCLS) estimator [46] to minimize the 2D spherical LS cost function in Equation (13) by a constrained optimization. The optimization procedure is presented in detail in [44, 46]. As stated in Section 4.2, the global TDOA localization with more than three ARIR perspectives yields two possible minimumLS directsound locations that are symmetric with regard to the horizontal ARIR plane. A unique directsound event location is selected by minimizing the angular error function (21).
Apart from a stable directsound location, the global directsound localization allows to estimate and compensate for a uniform system delay (as also used in Sect. 3). Moreover, microphone positioning errors of ARIR measurements, such as unintended rotations, can be detected and readjusted by an ARIR rotation according to the estimated directsound DOA.
4.4 ARIRtriplet soundevent localization
In contrast to the directsound event, small location fluctuations can be assumed to stay inaudible when the listener moves through different local ARIR triplets. Therefore, a TDOAbased localization in ARIR triplets offers sufficient accuracy at minimal combinatorial complexity when matching possible peak combinations.
We propose to use the spherical intersection (SX) estimator [45] as TDOAbased sound event localizer, for which the LS error function (18) of a perspective triplet (P = 3) is zeroed. It is computationally less complex than the LCLS approach and moreover offers a closedform solution. As the SX estimator is originally designed for threedimensional receiver arrays and P ≥ 3, we adapt the formalism to purely horizontal receiver triplets.
Zeroing the 2D spherical LS error (36) for an ARIR triplet with i ∈ {1, 2, 3} and solving for x_{t,2D} yields,(23)
This is equal to a straight line equation, which implies that x_{t,2D} is a function of the unknown soundevent distance r_{t}. The relation to the 3D coordinates lies in,(24)which is transformed to the quadratic equation,(25)
Equation (25) indicates that r_{t} relates to the absolute value of the unknown soundevent height z_{t}. Source localization with TDOA triplets turns out to yield an arbitrary source position on a vertical hyperbola that is symmetric with regard to the horizontal plane of the ARIR triplet (cf. Fig. 5). The soundevent position candidates are found as positive and real solution of (25) for any preselected z_{t}, which completes (23) to,(26)
A unique soundevent position is found by the abovementioned angular error function (21). Specifically, we search the soundevent candidate that minimizes the angular error within a predefined range of possible z_{t} values that is limited by the maximum time of flight T_{i},(27)
For the implementation of (27), we propose a grid search algorithm in steps of e.g. Δz_{t} = 0.1 m, yielding a sufficiently accurate result at low implementation and computation effort.
4.5 ARIRtriplet peak matching
The objective of the peak matching is to find peaks in a triplet of neighboring ARIRs that correspond to commonly detected sound events, for instance such stemming from the image sources of early reflections (cf. Figs. 6 and 7). To this end, we initially preselect peak combinations within a window of feasible flight time differences observed by the ARIR triplet. From these preselected arrival times, matching combinations get picked, whose TDOAbased soundevent locations are geometrically consistent with the DOAs and amplitudes observed in the three ARIRs.
Figure 6 Firstorder wall reflection, when x_{s} is the directsound source and is the soundevent position of the mth peak match corresponding to an image source.
Figure 7 Peak matching result of the 10 greatest ARIR triplet peaks (directsound peak and 9 early reflections).
In detail, we propose an iterative peak matching that always starts with the greatest unmatched peak in the ARIR triplet h_{i}(t), i ∈ {1, 2, 3} as reference peak. Hereafter, we denote this reference peak TOA by T_{A} and the corresponding ARIR perspective by x_{A}, A ∈ {1, 2, 3}. All unmatched peaks in the remaining two inferior ARIRs B, C ∈ {1, 2, 3} can be limited to those TOAs T_{B,C} whose TDOAs stay within a time window of the maximally observable flight time difference,(28)as defined by the spacing of the two inferior, neighboring ARIR perspectives x_{B,C} to the one observing the reference peak, i.e. x_{A}. Whenever any of the two inferior ARIRs exhibits more than one peak TOA candidate within this window, multiple candidates of the TOAs T_{B} and T_{C} could be combined with the TOA T_{A} of the reference peak to a TDOA triplet {T_{A}, T_{B}, T_{C}} for localization. The following cost function is introduced to retrieve the combination that is most consistent,(29)
It penalizes geometrical inconsistency with regard to directions and amplitudes observed according to the jointly localized soundevent position , which is initially estimated for each preselected TOAtriplet using the adapted SXbased localization approach described in Section 4.4. The cost function (29) involves the angular mismatch J_{ang}() (21) between the estimated peak DOAs θ_{i}(T_{i}) and the direction of each soundevent position θ_{x,i}() from the ith ARIR perspective, for i ∈ {1, 2, 3}. Moreover, it contains a peak amplitude error (32) considering the ratio of peak amplitudes (T_{i}) according to the estimated soundevent distance. Assuming free sound propagation, the distance law demands,(30)which can be reformulated by,(31)
However, as for multiple wall reflections with unknown attenuation, higherorder reflections need not necessarily fulfill free field attenuation conditions. Hence, we suggest to relax the distance law criterion by attenuating the denominator of (31) with an exponential factor α(t), assuming equal peak amplitudes of later coincident reflections. We define α(t = T_{i,DS}) = 1 ( distance law) for the directsound peak and α(t > T_{i,DS} + 50 ms) → 0 (equal peak amplitudes) for later reflections. The peak amplitude error function measures the deviation of the resulting weighted peak amplitudes ,(32)
Both, the angular error (21) and the peak amplitude error (32) are limited to values ≤1.
For each reference peak, the most consistent result can thus be selected from all possible combinations that fulfill (28) by minimizing the inconsistency (29). The corresponding soundevent position is localized by,(33)where m ∈ {1, …, M} denotes the peak matching index. m = 1 corresponds to the matched directsound peaks with the globally localized source position . Consequently, m = 2 denotes the match of the greatest early reflection corresponding to the tripletlocalized soundevent position , which most likely corresponds to an image source of a firstorder reflection. The peak matching is iterated over the next unmatched reference peak, until a desired number of peak matches M has been found.
4.6 Extrapolation of matching ARIR peak segments
This section takes up the information about matched peaks in ARIRtriplets to commonly extrapolate ARIR segments around those matched peaks to the desired listener perspective x_{d}.
Initially, ARIR segments of equal length are cut around the peaks of each matched peak triplet m ∈ {1, …, M}. We define each segment to start 16 samples before the estimated peak TOA T_{i} and end at least 16 samples before the earliest successive peak, however limited to a total segment length staying below 3 ms. This allows to preserve temporal, directional and level information present in the ARIR peak segments in a preferably longenough context. For smooth transitions between ARIR segments, the boundaries of each segment are crossfaded by an overlapping cos^{2} halfwindow of 16samples length.
Subsequently, we shift matching ARIR peak segments consistently with regard to the current location of a variableperspective listener position by perspective extrapolation as described in Section 2.2 (7) with . The resulting extrapolated ARIR segment of the ith ARIR according to the mth peak match with soundevent position is denoted by .
5 Variableperspective ARIR rendering
We proposed a system for rendering ARIRs in six degrees of freedom (6DoF) employing the ARIR perspective extrapolation with information retrieved (i) from all the ARIRs for the directsound event, (ii) from ARIR triplets for early sound events, and (iii) from individual ARIRs for the remaining residual sound events. The system targets a variableperspective interpolation only using the extrapolated ARIRs of the perspective triplet around the listener position, within a horizontally distributed ARIR grid of arbitrary Ambisonic order N ≥ 1. As most ARIR grids still are firstorder Ambisonic (e.g. [34]), directional enhancement of firstorder ARIRs offers a meaningful improvement. For this purpose, we integrate the ASDM directional enhancement as optional component of the proposed variableperspective ARIR rendering. Figure 8 shows the block diagram of the full ARIR interpolation system.
Figure 8 Block diagram of the proposed variableperspective ARIR rendering using a parametric, positiondependent interpolation of a horizontally distributed ARIR triplet.
We assume the extrapolation of the jointly, globally localized directsound event to be most accurate and temporally/directionally contextpreserving, followed by the ARIRtripletbased early soundevent extrapolation, and finally the singleARIRbased extrapolation. While the extrapolation of direct and early sound events is welldefined, we build a distinction to the singleARIR extrapolation in terms of an ARIR residual. Residual ARIR components are defined as parts that could not be jointly localized in the triplet, or such that are diffuse.
5.1 Interpolation of direct sound and matched peaks
Section 4 described the matching of the M most distinct ARIR peak triplets and the timealigned perspective extrapolation of corresponding ARIR peak segments to the desired listener position according to a globallylocalized directsound source and tripletlocalized reflection sound events.
While geometric time alignment of the hereby extrapolated ARIR segments is considered to be already rather precise in matching the two ARIRs containing the inferior peak segments to their corresponding mth ARIR reference peak segment, temporal misalignment in the range of a few samples can still occur. We propose a refined time alignment by shifting the inferior ARIR peak segments as to maximize their crosscorrelations with their corresponding reference ARIR peak, for each matching index m. Hereby, a predominantly constructive superposition of ARIR peak samples can be ensured for their linear interpolation.
From the accordingly extrapolated and timealigned peak segments of the three neighboring ARIRs, we compute an interpolated ARIR peak segment for each peak match m at the variable listener perspective by linear, distanceweighted (1) superposition of ,(34)
Regardless of the time alignment and its refinement, there may still be components that can only add up stochastically rather than additively. To avoid unintentional level variations between the individual, interpolated ARIR peak segments, we propose to control and correct the resulting RMS level of each interpolated peak by a gain factor,(35)where and are the omnidirectional, zerothorder channels of respectively . Finally, the ARIR d_{p}(t) containing all interpolated matched peak segments is computed by,(36)
Because of the effort required, we propose to restrict the matching and interpolation procedure to a limited number of loudest early ARIR peaks within the first 50…75 ms after the direct sound, e.g., about M = 10 matches for a mediumsized room. This choice performed well in the scenarios evaluated in Section 6 and mostly comprises all prominent early reflections in about half the mixing time [41, 42]. It moreover prevents peak matching errors that potentially arise from loweramplitude peaks thereafter, which gradually become less sparse. One can consider suitably enlarging this number of peak matches to more accurately present prominent early reflections for more complex, sparse reflection geometries or larger rooms. Figure 9 shows the result of the positiondependent interpolation of M = 10 matched peaks of an ARIR triplet with r = 2 m spacing (blue). Apart from the obvious gaps between the peaks, this interpolation reproduces a control RIR (gray) measured between the ARIR perspectives fairly well.
Figure 9 Interpolated matched peaks d_{p}(t) according to a globally localized directsound event and tripletlocalized reflectionsound events in comparison to a reference RIR h_{ref}(t) measured at the target listener position.
5.2 Interpolation of ARIR residuals
The sound events jointly localized in an ARIR triplet correspond to peak segments that were extrapolated and interpolated at high accuracy. Removing those segments from the three ARIRs of the triplet leaves three residual ARIRs for i ∈ {1, 2, 3},(37)
Even though the most prominent peaks in early residual ARIRs are zeroed, there may still be valuable nondiffuse parts in between, with distinct directional information, such as smaller, poorly localizable early reflections or diffraction. As these three residuals may moreover convey important parts of the room impression, we desire a technique for their extrapolation from any of the three perspectives to the desired perspective of the listener before superposition. For this purpose, the singleARIR extrapolation approach based on the simplistic instantaneous soundevent localization described in Section 3 is applicable. After singleperspective extrapolation of each early residual ARIR of the triplet to the desired listener perspective, we interpolate the resulting residual ARIRs by linear, distanceweighted combination,(38)where are the extrapolated residual ARIRs according to Section 3.2. The spectrum of the interpolated residual can depend on the particular interference as well as on remaining spectral artifacts due to the segmentation and resampling of extrapolated residuals. To compensate for this, we apply a correction of the temporal spectral envelopes, similar to the one done for ASDM directional enhancement described in [32]. Specifically, this correction restores the shorttime energy of the interpolated residual ARIR (41) to match the desired, average shorttime energy of the unprocessed residual ARIRs (40), in thirdoctave bands. This is accomplished by multiplication with the thirdoctave weights depending on the Ambisonic order and the time instant,(39)(40)(41)
Here, h_{r,i}(t) are the omnidirectional, zerothorder channels of the residual ARIRs h_{r,i}(t) and is the order n and degree m channel of the interpolated residual . F_{b}{·} is a perfectlyreconstructing zerophase onethirdoctave filter and F_{av}{·} denotes a time averaging over 10 ms.
5.3 Merged interpolated peaks and residual ARIRs
The final interpolated ARIR d(t) at the listener position is obtained by summing up the interpolated peaks d_{p}(t) and the interpolated residual ARIRs d_{r}(t) (cf. Fig. 10). An additional rotation to the listener’s head orientation ψ_{d} enables the convolutionbased spatial auralization of any singlechannel signal s_{in}(t) at a desired listener perspective in the captured acoustic environment,(42)(43)where s_{d}(t) is the Ambisonic signal auralized at the variable listener perspective and is an Nthorder spherical harmonics rotation matrix as described in Section 2.2 (6) that rotates the azimuth and zenith of the interpolated ARIR according to the listener’s head orientation.
Figure 10 Interpolated ARIR d(t) in comparison to a reference RIR h_{ref}(t) measured at the target listener perspective.
5.4 Realtime interpolation from intermediate finemeshed ARIRs
Due to nonnegligible computational costs, a realtime capable algorithm for all the steps in Figure 8 would be quite demanding, even if all positionindependent operations are carried out in advance. This section therefore presents a realtime capable system based on an offlinerendered, finemeshed grid of interpolated ARIRs and a simplified interpolation thereof at the expense of increased memory requirements.
Initially, the coarse ARIR grid is interpolated to a sufficiently fine ARIR grid using the proposed algorithm. We propose a grid spacing of e.g. r = 0.25 m, where perceptible but moderate directional and timbral differences appear between neighboring interpolated ARIRs. The choice of the grid spacing is a tradeoff between a preferably fine ARIR resolution and limited memory requirements. The realtime 6DoF ARIR rendering can then be achieved by a lowcost interpolation of the precomputed ARIR grid. We propose to interpolate the three closest precomputed ARIRs d_{i}(t), where early ARIR parts are linearly interpolated and the late ARIR part, e.g. for t > 100 ms, is solely taken from the nearest neighbor.
The neighboring ARIRs of the refined grid predominantly contain TOA shifts and nearly no directional variation. And yet, pure linear interpolation would not work. For instance, the maximum possible TDOA between neighboring grid points with r = 0.25 m is ΔT_{DS,max} ≈ 0.73 ms and linear ARIR interpolation could yield comb filtering with a clearly noticeable first notch at a frequency as low as f ≈ 700 Hz. To reduce the most dominant comb filter that is usually induced by the temporal deviation of the directsound peaks, we propose a time alignment of the precomputed ARIRs d_{i}(t) compensating for the directsound peak TOA differences. To this end, the early ARIRs are shifted to a common directsound peak TOA,(44)before linear interpolation,(45)where T_{DS,i} are the directsound TOAs and g_{i}(x_{d}) are the distancedependent amplitude weights (1) of the precomputed ARIR triplet d_{i}(t). Figure 11 exemplarily shows the influence of the time alignment on the spectral difference ΔD(f) between the magnitude spectrum of the interpolated ARIR d(t) and the averaged magnitude spectrum of each d_{i}(t), i ∈ {1, 2, 3}.
Figure 11 Spectral differences ΔD(f) between the interpolated ARIR and the reference ARIR spectrum for different realtime interpolation methods.
As linear interpolation of timealigned ARIRs may still cause small undesirable artifacts such as spectral ripple or rolloff (cf. Fig. 11 for f > 10 kHz), an additional spectral correction of the temporal envelope in onethirdoctave bands as described in Section 5.2 (39) is reasonable and also displayed in Figure 11.
When highly directional sources are involved, early reflection peaks could exceed the direct sound level and thus directsound time alignment only would not prevent distinct comb filtering. While unproblematic in this paper, an alternative approach could consider adapting realtime dynamic time warping as in the BRIR interpolation approach of [26]. It improves interpolation of closely spaced ARIRs by avoiding small differences in timing. Another feasible alternative could separate realtime rendering of finemeshinterpolated ARIR residuals from rendering of the M most distinct matchingpeak sound events of the current, coarse ARIRtriplet. These M few, short soundevent segments can still be efficiently convolved, extrapolated (time, level, rotation), and linearly interpolated while rendering in real time.
5.5 Timevariant overlapadd convolution
We implemented the realtime 6DoF auralization using a STFTbased convolution in frames of T_{s} = 1024 samples with an ARIR update after each frame. To this end, we split the current interpolated ARIR d(t) and the recent equallength section of the singlechannel input signal s_{in}(t) into N_{s} nonoverlapping segments of length T_{s} and compute a 2T_{s}point DFT of each segment,(46)
The Ambisonic output signal s_{d}(t) is then updated after each T_{s} period by overlapadd of the convolved Ambisonic output frame s_{out}(t),(47)where denotes a 2T_{s}point inverse DFT.
6 Listening experiment evaluation
To finalize our investigations, we carried out a listening experiment to evaluate the effectiveness of the various system components on perceptual features, such as localization and sound coloration. Specifically, the influence of separated versus jointly localized early sound events as well as the extrapolation of residual ARIRs prior to their interpolation was of particular interest. We used the most basic interpolation method A, the simple distanceweighted linear combination of the closest ARIR triplet (2), as comparison to more complex configurations B…E. As listed in Table 1, configurations B, C are characterized by a separate interpolation of the directsound peak (DS) only and D, E by interpolation of eleven matched peaks (DS + 10 early reflections, ERs) (cf. Sect. 5.1). Furthermore, B, D apply no extrapolation of the residual ARIRs, i.e. the unmodified residual ARIRs are linearly interpolated by distanceweighted superposition as done in A, whereas C, E additionally extrapolate the residual ARIRs before interpolation (cf. Sect. 3.2).
Configurations of presented stimuli.
6.1 Experiment setup
The variableperspective ARIRs for convolutionbased auralization were interpolated from a horizontal firstorder ARIR grid with equidistant r = 2 m spacing. Besides a measured dataset^{2} with 30 firstorder ARIR positions recorded in the IEM CUBE (T_{60} ≈ 0.65 s), we simulated a firstorder ARIR grid using the default settings of the “medium room” of the MatlabToolbox MCRoomSim^{3} [47], however with reduced room dimensions (14 × 10 × 4.1 m) and room absorption (80% of the default value). Both the measured and simulated ARIR grids were directionally enhanced to 5thorder by ASDM. For the rendering of stimuli^{4}, we used the realtime capable method described in Section 5.4. To this end, offline interpolation was done to a finemeshed 5thorder ARIR grid with r = 0.2 m spacing with each configuration A…E. On this refined grids, realtime capable interpolation was applied including the time alignment and spectral correction described above.
The stimuli were presented to the listeners with headtracked Beyerdynamic DT770 Pro headphones in an anechoic room. For the interactive head rotation and binauralization of the 5thorder Ambisonic stimuli, we used the SceneRotator and BinauralDecoder [48, 49] ([38], Ch. 4) of the IEM plugin suite^{5}. A graphical user interface for multistimulus trials, similar to MUSHRA testing [50], was used for evaluation, which enabled arbitrary repetition and pair comparisons of the presented stimuli. All stimuli were presented in randomized order.
The listening experiment consisted of three parts. In the first part, a measured ARIR triplet was used to interpolate an ARIR with each configuration A…E at a static listener position inside the ARIR perspectives. The listeners were asked to rate the,
perceived similarity of localization, in particular the direction and distance impression of the signal (stimulus: speech),
perceived similarity of sound coloration (pink noise),
In the second and third part, dynamic listener perspectives were evaluated (cf. Fig. 12). To this end, we rendered variable ARIRs at a moving listener perspective offline with an update every 1024 samples and auralized the output signal using the realtime capable convolution described in Section 5.5. The second part auralized a virtual walk on a straight line through the measured room (IEM CUBE) based on the recorded ARIR grid. No reference signal was available in this part.
Figure 12 Measured (Part 2) and simulated (Part 3) 5thorder ARIR grids used for the variableperspective ARIR interpolation at a dynamic listener perspective.
In the third part, we used the simulated ARIR grid to auralize the stimuli A…E of a virtual walk on a circular path around the source position. Additionally, we utilized the room simulation to simulate ARIRs in steps of 2 cm on the circular path. This enabled to render a simulated reference signal S for comparison. The listeners were asked to rate the,
perceived smoothness of localization, in particular of the direction and distance impression (stimulus: speech),
perceived smoothness of sound coloration (pink noise).
6.2 Listening experiment results
19 experienced listeners with an average age of 27 took part at the listening experiment. They needed 23 min on average to evaluate the presented stimuli. Responses of one listener were unreliable and excluded from the evaluation as they contained a standard deviation that was 2.5 times larger than the standard deviation of other listeners’ responses for the hidden reference. The similarity of the results of Part 2 and 3 allowed to pool and commonly evaluate the ratings of dynamic listener perspectives (note that the sample size of S is half the sample size of A…E, since no reference was available in Part 2). Figures 13 and 14 show the median and 95% confidence intervals of the ratings. For evaluation, we computed univariate ANOVAs with repeated measures for more than two paired samples. The significance between presented stimuli was evaluated via post hoc Bonferroni tests.
Figure 13 Median and 95% confidence intervals of the ratings for a static listener perspective with regard to a measured reference.
Figure 14 Median and 95% confidence intervals of the ratings for a variable listener perspective.
6.2.1 Static listener perspective
Perceived similarity of localization with regard to a given reference: Most listeners recognized the hidden reference (HR) to be identical with the reference stimulus (median = 1). The lowestrated condition A, the linearly interpolated ARIR triplet, significantly differs from all other stimuli (p < 0.001), whereas no significant differences are found between B, C, D, E (p = 0.25).
Perceived similarity of coloration with regard to a given reference: Most listeners recognized the hidden reference (HR) to be identical with the reference stimulus (median = 1). The ratings of A are significantly lower than all other stimuli (p < 0.001). Furthermore, stimuli D, E, characterized by a higher number of interpolated matched peaks, were rated significantly better than B, C (p < 0.001), whereas there is no significant difference between B and C or between D and E (p = 1).
6.2.2 Variable listener perspective
Perceived smoothness of localization: The simulated signal S is rated highest (median = 0.83, mean = 0.77), closely followed by the full interpolation system E (median = 0.79, mean = 0.76). The lowestrated condition A significantly differs from all other stimuli (p < 0.001). However, no significant difference is observed to distinguish between the simulated reference S and the configurations B, C, D, E (p = 0.36).
Perceived smoothness of sound coloration: The simulated signal S is rated highest (median = 0.80, mean = 0.75), closely followed by the full interpolation system E (median = 0.75, mean = 0.75). Significant differences are determined between S, E and A, B, D (p < 0.001), whereas no significant differences are observed within S, C, E (p = 0.24) and within A, B (p = 1).
6.3 Discussion
The listening experiment proved that the proposed ARIR interpolation system distinctly outperforms the most basic, linear interpolation of the closest ARIR triplet for both static and dynamic listener perspectives.
Compared to the separate interpolation of the matched directsound peak only (B, C), an additional effort to jointly localize and interpolate the ten most prominent early reflections (D, E) is clearly superior in terms of the perceived sound coloration for static perspectives (cf. Fig. 13). However, an additional extrapolation of the residual ARIRs yields no further improvement when interpolating sufficiently many matched ARIR peaks (E) and thus can be omitted for static perspectives.
The evaluation of a timevariant, moving perspective shows no notable differences of the perceived smoothness of localization concerning any of the proposed configurations, except for the poorlyrated, plain linear interpolation (A), which was perceived to be largely static, though interrupted by abrupt changes in location and coloration. However, the joint localization and interpolation of the ten most prominent matched early reflections (D, E) was clearly superior concerning the perceived smoothness of sound coloration for variable perspectives. This matches with the observation that disturbing comb filter fluctuations can be distinctly reduced due to the positiondependent rendering of jointly localized prominent ARIR peaks. Other than for static listener perspectives, extrapolating the residual ARIRs before interpolation (C, E) clearly improves the perceived smoothness of sound coloration for variable perspectives, where the full system for interpolation (E) was rated similarly high as the simulated reference stimulus (S). This justifies applicability of the residual extrapolation based on the simplistic singleARIR localization of instantaneous sound events that could not be jointly localized. Even though this localization technique is less precise, it still grants a clear improvement in terms of a smooth transition of variable, positiondependent ARIR comb filters.
The ratings we obtained on localization do not appear quite as selective as those obtained for sound coloration in both of the scenarios evaluated. For little coloration in the static scene, many geometrically precisely rendered sound events were important (D, E), and for little coloration in the dynamic scene, the extrapolation of the residuals (C, E) was superior to plain linear interpolation. A DTWbased approach [24, 25, 36] extended to higherorder Ambisonics might appear worth examining as an alternative. While its localization might not be treated as accurately, its timealigning warping targets an interpolation avoiding coloration in loworder channels.
As often, the perception of artifacts and sound coloration in the investigated application appears to be less critical for speech signals compared to music or noise signals. Moreover, differences between the algorithmic configurations vanish in strongly reverberant environments with long and highly diffuse impulse response tails, which appear to be uncritical. Therefore, the proposed system proves to be relevant especially in rather weakly or medium reverberant environments and in applications with music.
7 Conclusion
In this paper, we presented a parametric Ambisonic room impulse response (ARIR) interpolation system that achieves convolutionbased auralization of a variable listener perspective when a grid of measured or simulated, spatially distributed ARIRs is available to describe the acoustic environment of interest. To improve the directivity and naturalness of spatial reproduction, it moreover considers an optional enhancement of the directional resolution when using firstorder ARIR grids. The fundamental auralization principle is to parametrically extrapolate the perspectives of a local ARIR triplet to the desired listener perspective preceding the linear interpolation of the three ARIRs. In particular, we detect distinct early ARIR peaks that can be assigned to common sound events, such as directsound source and image sources, and we jointly localize corresponding soundevent positions in the ARIR triplet around the variable listener position. What cannot be resolved in this scheme remains in the residual ARIRs, for which a simplistic instantaneous soundevent localization is applied based on singleperspective information. With such estimated soundevent positions, the three ARIRs can be extrapolated in time segments that preserve the temporal and directional context as much as possible when extrapolated by reassigning direction, time, and level of the segments with regard to what would be observed at the desired listener perspective. Finally, a linear, distanceweighted interpolation is employed that restores the spectral and temporal RMS level of the resulting ARIR to compensate for varying interference. We furthermore introduced a realtime capable system based on a simplified interpolation from an offlineinterpolated, finemeshed ARIR grid.
Conclusively, the proposed ARIR interpolation system was evaluated at different algorithmic settings in a listening experiment, which proved a distinctly better quality in terms of localization and sound coloration compared to a basic, distanceweighted linear interpolation. But also the proposed steps that appear to require extra efforts could be supported and justified by the results of the experiment. Not as much in terms of localization but more in terms of a minimal sound coloration, the extrapolation of the residual early sound events was rated superior when the listener perspective is timevariant. For a static listener, raising the number of jointly localized early sound events from one to eleven was rated superior.
As the techniques discussed in our evaluation are not the only ways of obtaining interpolated ARIRs, the underlying ARIR measurements^{2} and the resulting processed binaural and Ambisonic experimental stimuli^{4} are made available online for reference and to encourage comparative studies.
The authors filed priority rights for the method described herein [51].
Conflict of interest
Author declared no conflict of interests.
All presented stimuli are available (binaural and in 5thorder Ambisonics) on https://phaidra.kug.ac.at/o:104443
References
 M. Vorländer: Auralization. Springer Publishing, 2010. [Google Scholar]
 L. Savioja, J. Huopaniemi, T. Lokki, R. Väänänen: Creating interactive virtual acoustic environments. Journal of the Audio Engineering Society 47, 9 (1999) 675–705. [Google Scholar]
 F. Brinkmann, L. Aspöck, D. Ackermann, S. Lepa, M. Vorländer, S. Weinzierl: A round robin on room acoustical simulation and auralization. The Journal of the Acoustical Society of America 145, 4 (2019) 2746–2760. [CrossRef] [PubMed] [Google Scholar]
 T. Pihlajamäki, V. Pulkki: Synthesis of complex sound scenes with transformation of recorded spatial sound in virtual reality. Journal of the Audio Engineering Society 7/8, 63 (2015) 542–551. [CrossRef] [Google Scholar]
 E. FernandezGrande: Sound field reconstruction using a spherical microphone array. The Journal of the Acoustical Society of America 139, 3 (2016) 1168–1178. [CrossRef] [PubMed] [Google Scholar]
 A. Plinge, S.J. Schlecht, O. Thiergart, T. Robotham, O. Rummukainen, E. Habets: Sixdegreesoffreedom binaural audio reproduction of firstorder ambisonics with distance information, in Audio Engineering Society Conference: 2018 AES International Conference on Audio for Virtual and Augmented Reality. 2018. [Google Scholar]
 A. Allen: Ambisonic Soundfield Navigation using Directional Decomposition And Path Distance Estimation. US Patent and Trademark Office, Washington DC, 2019. US Patent No. 10,182,303. [Google Scholar]
 M. Kentgens, A. Behler, P. Jax: Translation of a higher order ambisonics sound scene based on parametric decomposition, in IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP). 2020, pp. 151–155. [Google Scholar]
 F. Schultz, S. Spors: Databased binaural synthesis including rotational and translatory headmovements, in Audio Engineering Society Conference: 2013 AES International Conference on Sound Field ControlEngineering and Perception. 2013. [Google Scholar]
 Y. Wang, K. Chen: Translations of spherical harmonics expansion coefficients for a sound field using plane wave expansions. The Journal of the Acoustical Society of America 143 (2018) 3474–3478. [CrossRef] [PubMed] [Google Scholar]
 N. Mariette, B. Katz: SoundDelta – Largescale, multiuser audio augmented reality, in Proceedings of the EAA Symposium on Auralization. 2009, pp. 37–42. [Google Scholar]
 E. Patricio, A. Ruminński, A. Kuklasiński, Ł. Januszkiewicz, T. Żernicki: Toward six degrees of freedom audio recording and playback using multiple ambisonics sound fields, in Audio Engineering Society Convention 146. 2019. [Google Scholar]
 G.D. Galdo, O. Thiergart, T. Weller, E. Habets: Generating virtual microphone signals using geometrical information gathered by distributed arrays, in IEEE Workshop on Handsfree Speech Communication and Microphone Arrays. 2011. [Google Scholar]
 O. Thiergart, G.D. Galdo, M. Taseska, E. Habets: Geometrybased spatial sound acquisition using distributed microphone arrays. IEEE Transactions on Audio, Speech, and Language Processing 21, 12 (2013) 2583–2594. [Google Scholar]
 J.G. Tylka, E.Y. Choueiri: Soundfield navigation using an array of higherorder ambisonics microphones, in Audio Engineering Society Conference: 2016 AES International Conference on Audio for Virtual and Augmented Reality. 2016. [Google Scholar]
 J.G. Tylka, E.Y. Choueiri: Domains of practical applicability for parametric interpolation methods of virtual sound field navigation. Journal of the Audio Engineering Society 67, 11 (2019) 882–893. [CrossRef] [Google Scholar]
 J.G. Tylka: Virtual Navigation of AmbisonicsEncoded Sound Fields Containing NearField Sources. Ph.D. thesis, Princeton University, 2019. [Google Scholar]
 P. Grosche, F. Zotter, C. Schörkhuber, M. Frank, R. Höldrich: Method and Apparatus for Acoustic Scene Playback. WO Patent, WIPO/PCT, European Patent Office, Rijswijk, 2018. WO 2018/077379 A1. https://patentscope.wipo.int/search/en/detail.jsf?docId=WO2018077379&tab=PCTBIBLIO. [Google Scholar]
 T. Deppisch, A. Sontacchi: Browser application for virtual audio walkthrough, in Forum Media Technology & All Around Audio. 2017. [Google Scholar]
 D. Rudrich, M. Frank, F. Zotter: Evaluation of interactive localization in virtual acoustic scenes, in Fortschritte der Akustik – DAGA. 2017. [Google Scholar]
 D.R. Méndez, C. Armstrong, J. Stubbs, M. Stiles, G. Kearney: Practical recording techniques for music production with sixdegrees of freedom virtual reality, in Audio Engineering Society Convention 145. 2018. [Google Scholar]
 A. Neidhardt, N. Knoop: Binaural walkthrough scenarios with actual selfwalking using an HTC Vive, in Fortschritte der Akustik – DAGA. 2017, pp. 283–286. [Google Scholar]
 S. Werner, F. Klein, G. Götz: Investigation on spatial auditory perception using nonuniformspatial distribution of binaural room impulse responses, in Proceedings of the ICSA. 2019. [Google Scholar]
 G. Kearney, C. Masterson, S. Adams, F. Boland: Towards efficient binaural room impulse response synthesis, in EAA Symposium on Auralization, Finland. 2009, pp. 106–111. [Google Scholar]
 C. Masterson, G. Kearney, F. Boland: Acoustic impulse response interpolation for multichannel systems using dynamic time warping, in Audio Engineering Society Conference: 35th International Conference: Audio for Games. 2009. [Google Scholar]
 V. GarciaGomez, J.J. Lopez: Binaural room impulse responses interpolation for multimedia realtime applications, in Audio Engineering Society Convention 144. 2018. [Google Scholar]
 A. Neidhardt: Data set: BRIRs for positiondynamic binaural synthesis measured in two rooms, in Proceedings of the ICSA. 2019. [Google Scholar]
 B. Bacila, H. Lee: 360 degree binaural room impulse response (BRIR) database for 6dof spatial perception research, in Audio Engineering Society Convention 146. 2019. [Google Scholar]
 E. Stein, M.M. Goodwin: Ambisonics depth extensions for six degrees of freedom, in Audio Engineering Society Conference: 2019 AES International Conference on Headphone Technology. 2019. [Google Scholar]
 J. Merimaa, V. Pulkki: Spatial impulse response rendering, in Proceedings of the 7th International Conference on Digital Audio Effects. 2004, pp. 139–144. [Google Scholar]
 S. Tervo, J. Pätynen, A. Kuusinen, T. Lokki: Spatial decomposition method for room impulse responses. Journal of the Audio Engineering Society 61, 1 (2013) 17–28. [Google Scholar]
 M. Zaunschirm, M. Frank, F. Zotter: BRIR synthesis using firstorder microphone arrays, in Audio Engineering Society Convention 144. 2018. [Google Scholar]
 L. McCormack, A. Politis, O. Scheuregger, V. Pulkki: Higherorder processing of spatial impulse responses, in Proceedings of the 23rd International Congress on Acoustics. 2019, pp. 9–13. [Google Scholar]
 R. Stewart, M. Sandler: Database of omnidirectional and Bformat room impulse responses, in IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP). 2010, pp. 165–168. [Google Scholar]
 A. Southern, J. Wells, D. Murphy: Rendering walkthrough auralisations using wavebased acoustical models, in 17th European Signal Processing Conference. 2009, pp. 715–719. [Google Scholar]
 V. Garca Gómez: Interpolation Techniques in Advanced Spatial Audio Systems. Master’s thesis, Universitat Politècnica de València, 2018. [Google Scholar]
 J. Ivanic, K. Ruedenberg: Rotation matrices for real spherical harmonics. Direct determination by recursion. The Journal of Physical Chemistry 100, 15 (1996) 6342–6347. [Google Scholar]
 F. Zotter, M. Frank: Ambisonics. SpringerOpen, 2019. [CrossRef] [Google Scholar]
 L. McCormack, V. Pulkki, A. Politis, O. Scheuregger, M. Marschall: Higherorder spatial impulse response rendering: Investigating the perceived effects of spherical order, dedicated diffuse rendering, and frequency resolution. Journal of the Audio Engineering Society 68, 5 (2020) 338–354. [CrossRef] [Google Scholar]
 M. Zaunschirm, F. Zotter, M. Frank: Binaural rendering with measured room responses: Firstorder ambisonic microphone vs. dummy head. MDPI Applied Sciences 10, 5 (2020). [Google Scholar]
 P. Götz, K. Kowalczyk, A. Silzle, E. Habets: Mixing time prediction using spherical microphone arrays. The Journal of the Acoustical Society of America 137, 2 (2015) EL206–EL212. [CrossRef] [PubMed] [Google Scholar]
 A. Lindau, L. Kosanke, S. Weinzierl: Perceptual evaluation of model and signalbased predictors of the mixing time in binaural room impulse responses. Journal of the Audio Engineering Society 60, 11 (2012) 887–898. [Google Scholar]
 C. Schörkhuber, P. Hack, F. Zotter, M. Zaunschirm, A. Sontacchi: Localization of multiple acoustic sources with a distributed array of unsynchronized firstorder ambisonics microphones, in Proceedings of the 6th Congress of the Alps Adria Acoustic Association. 2014. [Google Scholar]
 J. Neering: Optimization and Estimation Techniques for Passive Acoustic Source Localization. Theses, École Nationale Supérieure des Mines de Paris, 2009. [Google Scholar]
 H. Schau, A. Robinson: Passive source localization employing intersecting spherical surfaces from timeofarrival differences. IEEE Transactions on Acoustics, Speech, and Signal Processing 35, 8 (1987) 1223–1225. [Google Scholar]
 Y. Huang, J. Benesty, G.W. Elko, R.M. Mersereau: Realtime passive source localization: A practical linearcorrection leastsquares approach. IEEE Transactions on Speech and Audio Processing 9 (2001) 943–956. [CrossRef] [Google Scholar]
 A. Wabnitz, N. Epain, C. Jin, A. van Schaik: Room acoustics simulation for multichannel microphone arrays, in Proceedings of the International Symposium on Room Acoustics. 2010. [Google Scholar]
 C. Schörkhuber, M. Zaunschirm, R. Höldrich: Binaural rendering of ambisonic signals via magnitude least squares, in Fortschritte der Akustik – DAGA. 2018, pp. 339–342. [Google Scholar]
 M. Zaunschirm, C. Schörkhuber, R. Höldrich: Binaural rendering of ambisonic signals by headrelated impulse response time alignment and a diffuseness constraint. The Journal of the Acoustical Society of America 143, 6 (2018) 3616–3627. [CrossRef] [PubMed] [Google Scholar]
 ITU: ITUR BS. 15343: Method for the Subjective Assessment of Intermediate Quality Level of Audio Systems. 2015. [Google Scholar]
 F. Zotter, K. Müller: Method for Positiondependent Interpolation and Extrapolation of Ambisonic Room Impulse Responses. Provisional Patent Appl., Austrian Patent Office, Vienna, 2020. A 60169/2020. [Google Scholar]
Cite this article as: Müller K & Zotter F. 2020. Auralization based on multiperspective ambisonic room impulse responses. Acta Acustica, 4, 25.
All Tables
All Figures
Figure 1 Rendering of a variable listener perspective by interpolation of the three closest ARIR perspectives of a spatially distributed ARIR grid. Before interpolation, the three ARIRs are extrapolated to the desired listener perspective x_{d} by decomposition into localized sound events, which are reproduced at the listener perspective with reassigned direction, time, and level.

In the text
Figure 2 Extrapolation of an ARIR segment from its recording perspective x_{i} to a desired listener perspective x_{d}, given its instantaneous soundevent position .

In the text
Figure 3 Schematic illustration of singleperspective extrapolation by instantaneous soundevent trajectory (gray) according to (19) with three straightline segments , , of equal duration in the recorded ARIR (top time line). While level and direction remapping according to (a) are acceptable, temporal remapping (bottom time line) improves by resampling at original sampling speed, with segment time shifts quantized as their median time shift (b) (bottom time line).

In the text
Figure 4 Time shifts due to parallactic resampling of the instantaneous soundevent position from an extrapolated listener perspective at a displacement of x_{d} − x_{i} = 1 m and segmentation with medianquantized time shifts.

In the text
Figure 5 TDOA and DOAbased soundevent localization of the first early reflection (firstorder floor reflection) in an ARIR triplet. The cross marks the detected soundevent position, i.e. the point on the TDOAlocalized hyperbola with minimum angular deviation to the estimated DOAs. The directsound source is displayed as gray loudspeaker.

In the text
Figure 6 Firstorder wall reflection, when x_{s} is the directsound source and is the soundevent position of the mth peak match corresponding to an image source.

In the text
Figure 7 Peak matching result of the 10 greatest ARIR triplet peaks (directsound peak and 9 early reflections).

In the text
Figure 8 Block diagram of the proposed variableperspective ARIR rendering using a parametric, positiondependent interpolation of a horizontally distributed ARIR triplet.

In the text
Figure 9 Interpolated matched peaks d_{p}(t) according to a globally localized directsound event and tripletlocalized reflectionsound events in comparison to a reference RIR h_{ref}(t) measured at the target listener position.

In the text
Figure 10 Interpolated ARIR d(t) in comparison to a reference RIR h_{ref}(t) measured at the target listener perspective.

In the text
Figure 11 Spectral differences ΔD(f) between the interpolated ARIR and the reference ARIR spectrum for different realtime interpolation methods.

In the text
Figure 12 Measured (Part 2) and simulated (Part 3) 5thorder ARIR grids used for the variableperspective ARIR interpolation at a dynamic listener perspective.

In the text
Figure 13 Median and 95% confidence intervals of the ratings for a static listener perspective with regard to a measured reference.

In the text
Figure 14 Median and 95% confidence intervals of the ratings for a variable listener perspective.

In the text
Current usage metrics show cumulative count of Article Views (fulltext article views including HTML views, PDF and ePub downloads, according to the available data) and Abstracts Views on Vision4Press platform.
Data correspond to usage on the plateform after 2015. The current usage metrics is available 4896 hours after online publication and is updated daily on week days.
Initial download of the metrics may take a while.
